AI Smart Face Caparison Metal IP Dome

AI Smart Face Caparison Metal IP Dome

Features:

AI Face Recognition Access Control IP Metal Dome Camera

2.0mp 1080P Sony Starvis Sensor

6mm Fixed CS Lens

24pcs Infrared IR LED

Built-in ICR for Day/night vision

Two-way Audio Intercom

Dual Group Unlock Function

2 Ch Alarm Input and 1 Channal Alarm Output

Built in TF Card Slot (Support upto 128GB TF card)

PoE Optional

Vandalproof Metal Case for Indoor and Outdoor

AI Face Capture and Comparison

Intelligent Gender/Age Analysis

10000 Faces Storage.

IE Web Page, VMS, Onvif 2.6V

Support FTP E-mail Notification

Free Smart Phone App

Alarm Message Push to APP or E-mail

other AI Smart Functions: Human Shape Detection, Abnormal Sound Detection, Motion Detection, Perimeter Protection, Video Diagnosis



Enquiry

Specifications Send Inquiry Related Products

Model

TT-V22MAI

Produce Name

AI Face Capturing and Comparison Bullet IP Camera

System

Main Processing

Hi-silicon 3516CV500 (supports 16G / 32G // 64G /128GB EMMC)

Imaging Device

1/2.8 S0NY IMX327

Operating System

Embedded LINUX operating system

Human Face

Snapshot Mode

Auto mode, fast mode, optimal mode, custom mode

Recognition Ability

10 ~ 20 frames detection frame rate, up to 32 people per frame; maximum support of 150 people per second

Recognize Face Size

Face pixels 40 * 40-300 * 300

Attitude

Attitude pitch within 45 degrees, right and left can be captured within 90 degrees, oblique face angle within 45 degrees

Occlusion

Ordinary glasses, shorter stay in the sea, masks have no effect on recognition

Expression

Under normal circumstances, the expression does not affect recognition

Face Capture Rate

≥98% (to meet the above conditions)

Responding Speed

≤200ms

Face to Repeat

stand by

Face Quality Filtering

stand by

Face Dynamic Exposure Adjustment

stand by

Recognition Area

Full image recognition, support area optional setting, the minimum and maximum   pixels for detecting faces can be set, and the detection area can be set

Image Format

Support face matting, half body matting, whole body matting

Mobile Push Information

Multiple alarm graphic information

Upload Method

FTP, SDK call upload

Video

Video Coding Standards

H.264/H.265/H.265+

System Format

PAL 50HZ/NTSC 60HZ

Effective Resolution

1920*1080/1280*720

Effective Pixels

2.0M Pixels

Video Frame Rate

25fps

Video Stream

128kbps-12288kbps   (default variable bit rate)

Signal   to Noise Ratio

S / N ratio ≥50dB (auto gain off)

Minimum Illumination

Day mode 1Lux, night vision mode 0.01Lux

Day and Night Mode

Auto IRC Switch

AWB/BLC/AGC/WDR

Support Auto White Balance, Backlight Compensation, Increase Gain, Wide Dynamic

Electronic Shutter (AES)

AUTO/1/501/60-1/100,000sec

Video Output

VMS Client / Mobile APP Client

Motion Detection

stand by

Snapshot Function

stand by

Infrared

24pcs Infrared LEDs

IR Distance

25 meters

Lens

6mm Fixed CS Lens

Audio

Coding Standards

G.711U (Optional)

Audio Input

Passive microphone MIC / active pickup

Audio Output

External 8Ω / MAX 1.5W speaker

Video Management

Video Mode

Manual recording, alarm recording, timing recording

Video Save

EMMC (full function board) / PC side / NVR

Alarm

Alarm Input / Output

Stand  by

Alarm Trigger

Motion detection alarm, speaker alarm, alarm recording, snapshot, email, external   sound and light alarm

Internet

Network Protocol

HTTP, TCP/IP, IPV4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search

Connection

RJ45   network port

Other

TF Card Capacity

Optional support for up to 128G, Micro SD (SDHC / SDXC) card local storage

Operating Voltage

Standard DC-12V (wide voltage 10-16V)

Working Current

160mA ±10mA

Working Environment

-10 -+60

Housing

Metal Bullet Housing for Outdoor Weatherproof

Net Weight

1kg

Product Dimension

123mm *103mm
